Rotary Labeling Machine
- High‑precision Labelling: Stable ±0.5‑mm labelling accuracy (excluding defects of goods and stickers) for neat, aligned labels
- Adjustable Working Speed: 15‑50 items per minute, output adapts to manual feeding pace and product dimension
- Wide Compatibility: Supports items 20‑300 mm(L) ×20‑200 mm(W) ×50‑350 mm(H); bespoke sizing service available
- Flexible Label Specification: Fits labels 15‑200 mm long, 15‑170‑mm base‑paper width
- Large‑capacity Label Roll: 76 mm inner core, maximum 300‑mm outer‑diameter roll to cut frequent‑reloading downtime
- Heavy‑duty Solid Build: Compact overall dimension 1220×1250×1470 mm, 270‑kg sturdy frame for long‑time continuous‑run production
- Standard 220V/50HZ power supply : simple‑to‑operate rotary‑disc structure, suited for food, cosmetic and daily‑chemical factories
Performance and Features:
Our rotary‑disc labeling machine is a dependable self‑adhesive label applicator engineered for medium‑speed packaging‑line operation. Boasting dependable ±0.5‑millimetre labelling precision, this rotary labelling gear eliminates messy and crooked labels on your finished goods. Its working throughput ranges 15‑50 pieces every minute, whose rate can match your manual‑feeding rhythm and different‑sized containers.
Great adaptability stands out among its strengths. It accommodates work‑pieces from 20 mm‑300 mm in length, 20 mm‑200 mm in thickness/width and 50 mm‑350 mm in height. Custom‑made fixtures are available for your non‑standard‑dimension products. Applicable label sizes span 15–200 mm length and 15–170 mm backing‑paper width. The machine accepts label rolls with 76 mm inner diameter and up to Φ300 mm outer diameter, minimizing frequent label‑roll change‑over.
Constructed with a robust 270‑kilogramme body and footprint size L1220×W1250×H1470 mm, the machine runs under standard 220V/50HZ power supply. Well‑suited for round bottles, cans, jars and cylindrical containers of cosmetics, beverages, condiments and household supplies, the rotary‑disc labeller delivers steady‑duty performance for your daily packaging workflow.
Technical parameters:
| Label accuracy | ±0.5mm(Excluding product and label errors) |
| Label speed | 15-50Item/minute Related to product size and manual feeding speed |
| Applicable product size | length：20-300mm Width (thickness)：20-200mm height：50-350mm Can be customized according to product size |
| Applicable label size | length：15-200mm Width (base paper width) 15-170mm |
| Voltage | 220V/50HZ |
| Label roll inner diameter | Φ76mm |
| Max label roll out diameter | Φ300mm |
| Machine size | L1220xW1250xH1470mm |
| Gross weight | 270Kg |
